Chapter 6 Operations and Measurements RIGOL
DS4000E User’s Guide 6-45
source of cursor A. You can also press Source continuously to switch the
current source. The channels available include CH1 to CH4 and MATH.
When “None” is selected, cursor A and the measurement result will not be
displayed.
Note: Only channels currently turned on can be selected.
2) Use the same method to select the track source of cursor B.
5. Adjust the cursor positions
1) Press CursorA and turn the multi-function knob to adjust the
horizontal position of cursor A (X cursor). The adjustable range is limited
within the screen. The crossing point of the cursors is marked by an orange
rectangle.
2) Press CursorB and turn the multi-function knob to adjust the
horizontal position of cursor B (X cursor). The adjustable range is limited
within the screen. The crossing point of the cursors is marked by an orange
rhombus.
3) Press CursorAB and turn the multi-function knob to adjust the
horizontal positions of cursors A and B (X cursors) at the same time (the
horizontal distance between cursor A and B (X cursors) keeps unchanged).
The adjustable range is limited within the screen. The two crossing points
are marked by an orange rectangle (cursor A) and an orange rhombus
(cursor B) respectively.
Note: When any of CursorA, CursorB and CursorAB is currently selected,
you can turn the multi-function knob
continuously to quickly switch among
the three items.
