Chapter 7 Protocol Decoding RIGOL

DS4000E User’s Guide 7-31

and expressed by turquoise patch. When CRC is invalid, it is expressed by a

red patch.

 DTS: dynamic tail sequence; expressed by a light purple patch.

TSS Frame Type Frame ID PL Header CRC CYC

Data Tail CRC DTS
