RIGOL Chapter 10 Waveform Recording
10-8 DS4000E User’s Guide
4. Set the end frame
Press End Frame and turn the multi-function knob to set the end frame of
playback. The maximum range is from 1 to the number of frames recorded. The
default is the number of frames recorded.
Note:
 The actual range of the end frame is from the start frame currently set
(Start Frame) to the number of frames recorded.
 Please distinguish the end frame here from the end frame in the waveform
“Record” mode.
5. Execute the playback operation
After setting the desired playback parameters, you can press the menu key or
RUN/STOP to execute the playback operation.
Note: You cannot set the playback parameters after the playback operation
starts. Please set the playback parameters above before starting the playback
operation.
1) Start the playback operation
Press Operate, turn the multi-function knob to select “ ” and press
the knob or directly press the playback/pause shortcut key (
) at the
front panel; the oscilloscope starts the playback according to the current
settings.
During the playback process, the backlight of the playback/pause shortcut
key (
) is illuminated in yellow and flashes continuously. The number of
frame currently played back is displayed in the playback information at the
upper-right side of the screen and in Current Frame.
2) Pause the playback operation
During the playback process (the backlight of the playback/pause shortcut
key ( ) is illuminated in yellow and flashes continuously), press Operate
and turn the multi-function knob
to select “ ” and press the knob or
directly press the playback/pause shortcut key (
) at the front panel; the
oscilloscope pauses the playback operation. At this point, the backlight of
the playback/pause shortcut key (
) is illuminated in yellow and is
constant on.
When the playback operation is paused, you can adjust the Current
Frame according to your need (refer to “Manual Playback”); when the
playback operation is resumed, the oscilloscope will play back from the
frame specified in Current Frame.
