Chapter 12 Store and Recall RIGOL
DS4000E User’s Guide 12-13
Name Input Area: display the filename characters currently input.
Chinese Character Selecting Area: used to select the desired Chinese character.
Keyboard: used to input the specified character.
Upper-lower Case Switch: used to switch between English uppercase and
lowercase inputs. “
A
a”denotes lowercase and “
a
A” denotes uppercase.
Input Method Switch: used to switch between English and Chinese input
methods.
Example: create a file or folder with the name “
文件名”.
1. Select Chinese input method
If the current input method is “中”, please move to step 2. If the current input
method is “En”, turn the multi-function knob
to select “En” and press the
knob to switch to “中”.
2. Clear the pinyin input area and name input area
If there is no character in the “Pinyin Input Area” and “Name Input Area”, please
move to step 3. If there are characters in the “Pinyin Input Area”, press
Keyboard to select the “Keyboard” area and press Delete continuously to
delete all the characters in the pinyin input area in order. If there are characters
in the “Name Input Area”, press Name to select the “Name Input Area” and
press Delete continuously to delete all the characters in the name input area in
order.
3. Input the first Chinese character “文”
1) Input the pinyin “wen” in the “Pinyin Input Area”
Press Keyboard to select the “Keyboard” area, turn the multi-function
knob
to select the first letter “w” (or “W”) in the pinyin “wen” and press
the knob to input “w” in the “Pinyin Input Area”.
Use the same method to input the remaining letters “en” in the pinyin “wen”.
After finishing the input, the Chinese characters available are displayed in
the “Chinese Character Selecting Area”.
2) Select the desired Chinese character in the “Chinese Character Selecting
Area”
Press Chinese to select the “Chinese Character Selecting Area”, turn the
multi-function knob
to select “文” and press the knob to input “文” in
the “Name Input Area”.
