14. Message Box
Display the prompt messages.
15. Notification Area
Display the system time, sound icon, USB storage device icon and PictBridge
printer icon.
System Time: displayed in “hh:mm (hour:minute)” format. When printing
or storing the waveform, the output file will contain this time information.
Press Utility System System Time System Time to set the
system time in the following format.
yyyy-mm-dd hh:mm:ss (year-month-date hour:minute:second)
Sound Icon: when beeper is turned on,
is displayed. Press Utility
Sound to turn the beeper on or off.
USB Storage Device Icon: when the oscilloscope detects a USB storage
device, is displayed.
PictBridge Printer Icon: when the oscilloscope is correctly connected to a
PictBridge printer,
is displayed.
16. Function Setting Menu
Press MENU at the right of the screen continuously to unfold or fold the
function setting menu. When the function setting menu is unfolded, press any
softkey to activate the corresponding menu item (for menu items that include
submenus or multiple parameter items, the submenus or parameter items will
also be opened).
The following symbols might be displayed in the menu item or parameter item:
Denote that you can turn the multi-function knob
to select the
specified parameter item. The backlight of the multi-function knob
is illuminated when the parameter selection is valid.
Denote that you can turn the multi-function knob to modify the
parameter value. The backlight of the multi-function knob
is
illuminated when the parameter input is valid.
Denote that you can use the navigation knob to quickly adjust/locate
parameters. Turn the knob clockwise to increase the value and
counterclockwise to decrease the value. The inner knob is used for
fine adjustment and the outer knob for coarse adjustment (the
larger the rotation amplitude of the outer knob is, the faster the
To Next Page
