5
Controls and Features
Carrying strap
For carrying, hold the unit as shown below.
WARNING
When making measurements on exposed
rotating parts or power train parts of
machinery, proceed with utmost care to
ensure that the pickup or pickup cable do
not get caught in the machine.
14
16
Table of Contents
Organization of this Manual
3
For Safety
5
Warning
6
Precautions
7
Table of Contents
8
Outline
11
Controls and Features
13
Front Panel
13
Side Panel
16
Top Panel
17
Bottom Panel
18
Preparations
19
Power Supply
19
Connecting the Accelerometer PV-55
24
Trigger Input
25
Printer and Computer Connections
26
Setting the Date and Time
29
Using the Shoulder Belt
30
Display Explanation
31
Display Layout
31
Measurement Screens
32
Menu Screens
42
Menu Operation on Measurement Screen
54
Trigger Functions
55
Processing Principles
58
Mass Memory
60
Measurement
64
Use as a Vibration Meter
64
Use as a Spectrum Analyzer
66
Spectrum List Display
67
Time Waveform Display
68
Cursor Control
70
Recall Mode
71
Recalling Transient Store Data
72
Recalling Manual Store Data
76
Frequency Zoom Display Examples
78
Y Axis Zoom Display Examples
80
Printing
81
Compact Flash Card
82
Inserting a Card
82
Card Contents
89
Default Settings
98
Specifications
100
