12. Reduce the vibrating frequency until the required feed rate is obtained.
Vibrating drive operating
frequency
13. Check the load current; it must not exceed the maximum value!
The RNA - plug-in adapter ESZ-01 greatly facilitates start-up and, in particular, determination of
the load current.
14. Save the operating parameters chosen
Save and return to
main menu
If you are not sure whether the controller is in the factory default setting, select menu C210 "Retrieve param-
eters" as described under 4.5.10 to call up the default setting.
Attention:
In case of bumping of the bowl feeder during commissioning (very loud metallic noise):
Stop the controller immediately!
Commissioning without observing the above measures creates the risk of destroying the feeder
or parts thereof. This would void any warranty!
After successful commissioning you can activate the sensor amplifier and set the delay periods and soft
start/stop times, if required.
Two sensor inputs are integrated into the controller. They enable you to implement accumulation checks,
level checks, cycle monitoring and other monitoring tasks. The following basic assignments are made:
Sensor input 1 acts on channel 1, unless otherwise programmed in menu C006. Sensor input 2 is provided
for additional functions, see sensor linkage. The sensor inputs can be evaluated only if they are activated in
codes C004 and C005. The connection diagram is shown in the sensor plug connector (XS3).
3.6. Sensor inputs and sensor linkages
