RNA ESR 2000 User Manual

Rhein-Nadel Automation GmbH 7
VT-BA-ESR2000_EN_2023.docx
Mains voltage:
230 V AC, 50/60 Hz, +15 / -15%
115 V AC, 50/60 Hz, +10 / -15%
Output voltage:
0 ... 208 V
eff
/ 230 VAC; 0 ... 98V
eff
/ 115VAC
Load current, max.:
6 A
eff
Minimum load current:
80 mA
Output frequency
30 to 140 Hz
Internal fuse:
F1 = 10 A med.time lag
Control-circuit fuse
2A med.time lag
Soft start delay, soft stop delay:
0 ... 5 sec. separately adjustable
External setpoint:
0 ... 10V DC
Sensor inputs:
2
Enabling input:
24V DC (10-24VDC)
Sensor supply:
24V DC, max. 60 mA (per sensor input)
Sensor ON delay:
0 ... 60 sec. separately adjustable
Sensor OFF delay:
0 ... 60 sec. separately adjustable
Outputs:
2 relays (max. 6A 250V AC) / 2 floating changeover con-
tacts, 2 normally-open contacts carrying supply voltage
Status output:
2 optocouplers, max. 30VDC 10mA,
Ambient temperature:
0 ... 50° C
Cooling:
free convection
Mounting:
vibration-free
Degree of protection:
IP 54
Leakage current
Less than 2mA
Power loss
30W
Tag
Designation
Type
RNA article code
XS1
Load connector
5-pin (EMC)
31002329 (50Hz drive)
XS1
Load connector
5-pin (EMC)
31002325 (100Hz drive)
XS3
Male connector
5-pole, straight
35051144
XS3
Male connector
5-pole, right-angled
35002546
XS4
Female connector
7-pole, straight
35051153
XS4
Female connector
7-pole, right-angled
35002545
For XS3
Y adapter
for connection of 2 sensors
39905940
Bowl feeders and linear feeders, due to their mechanical design, can only be protected against damage by
operating them in a proper way.
This is why the electrical operating conditions must be adapted to the vibrating system. The following table
shows the variable safe operating ranges for the complete RNA product range.
Attention:
Uniform weight distribution on the bowl (balancing) is a prerequisite for a consistent and stable
feed rate.
A well balanced spring package is described in detail in the operating instructions for the vibratory
feeder.
3.3. Technical data
3.4. Accessories
3.5. Starting preparations
