• All specifications relate to installed condition ready for operation.
• All slots not used must be closed by protection caps or dummy plugs in order not to reduce the pro-
tection against accidental contact.
The compact controller is designed for operation of a vibratory bowl feeder or linear feeder.
The unit offers the following characteristic features:
- Power controller for vibrating motors with
variable output frequency, load current max. 6A
- Two sensor amplifiers with independently adjustable timers (On/Off delay).
- External enabling input, 24 VDC
- Two relay outputs and two optocouplers for status messages and other links.
- Membrane keypad for setting and changing the operating parameters in the set-up menus.
- Plug-type connections for
- Bowl feeder or linear feeder
- Sensors
- Communication
- Bipolar main disconnect switch.
The controller is compliant with the following standards:
EC EMC Directive 2014/35/EU
EC Low Voltage Directive
2014/30/EU
Applied harmonised standards:
DIN EN 60204, part 1
EN 61439-1
