RNA ESR 2000 User Manual

Rhein-Nadel Automation GmbH 8
VT-BA-ESR2000_EN_2023.docx
Table 1
Vibratory feeder mo-
tor type
Max. load cur-
rent
A
eff

Max. air gap on
magnet mm
Frequency
range
Magnet body colour
SRC - N 160 - 2
0.6
0.5
90...120 Hz
Black
SRC - N 200 - 2
1.2
0.5
90...120 Hz
Black
SRC - B 200 - 2
1.2
0.5
90...120 Hz
Black
SRC - N 250 - 2
2.6
1.2
90...120 Hz
Black
SRC - B 250 - 2
2.8
1.2
90...120 Hz
Black
SRC - N 400 - 1
3.8
2.8
45...60 Hz
Red
SRC - N 400 - 2
4.3
1.2
90...120 Hz
Black
SRHL 400 - 1
5.7
2.8
45...60 Hz
Red
SRHL 400 - 2
5.3
1.5
90...120 Hz
Black
SRC - N 630 - 1
5
2.8
45...60 Hz
Red
Table 2
Linear feeder
Motor type
Max. load cur-
rent A
eff

Max. air gap on
magnet mm
Frequency
range
Magnet body colour
SLL 175
0.07
0.8
90...120 Hz
Black
SLL 400
0.6
1
90...120 Hz
Black
SLL 800
1.4
3
45...60 Hz
Red
SLL 804 <1600
1.4
3
45...60 Hz
Red
SLL 804 1600
2.8
3
45...60 Hz
Red
SLF 1000-1000
2.8
2.5
45...60 Hz
Red
SLF 1000-1500
5.6
2.5
45...60 Hz
Red
GL 01
0.6
1.5
90...120 Hz
Black
GL 1
1.1
1.0
90...120 Hz
Black
SLK - N 6
1.4
2.5
45...60 Hz
Red
SLK - N 6 G
1.4
2.5
45...60 Hz
Red
RNA feeders have connecting cables of different colours for ease of distinction between vibrating frequen-
cies.
Cable colour
Mains frequency mode
Variable frequency mode
Black
50/ (60) Hz
45...60 Hz
Grey
100/ (120) Hz
90...120 Hz
Attention:
Make sure that the maximum values of load current and magnet gap are observed because oth-
erwise there is a risk of damage to feeder or controller!
Notice:
For smooth commissioning RNA offers an adapter of type ESZ 01 which can be plug-connected
between controller and feeder without any installation work. The adapter comprises measuring
devices for load current and coil voltage as well as a disconnect switch.
When a bowl feeder is delivered complete with ESR 2000 controller the operating parameters are
already set to suit the bowl feeder and stored in the 143 USER – 0 parameter.
All settings can be retrieved from the RNA archive.
3.5.1. Commissioning
