Robustel GoRugged R3000 Quad User Guide
RT_UG_R3000 Quad_v.1.2.0 02.07.2015 36 / 136
Confidential
in item “New PIN Code” and “Confirm New PIN Code”.
You can go to tab “Status” -> “Event/Log” and find out “AT+CPIN?” to check
what the status of the SIM card is.
PPPoE Bridge Setting
Enable PPPoE Bridge
PPPoE Bridge uses PPPoE to pass the IP address (and DNS server) that has
been assigned to R3000’s PPP interface by an ISP, to a PPPoE client which
connect to R3000’s LAN port.
Note: In PPPoE Bridge mode, Port Forwarding and DMZ will be unavailable
because packets received for the PPP interface are delivered directly to the
Ethernet interface. Similarly, packets received for the Ethernet interface are
sent to the PPP interface.
Connection Mode
Connection Mode
Select from “Always Online” and “Connect On Demand”.
Always Online: Auto activates PPP and keeps the link up after power on.
Connect On Demand: After selection this option, user could configure
Triggered by Serial Data, Triggered by Periodically Connect and Triggered
by Time Schedule.
Note: If you select several connect on demand polices, router only have to
meet one of them to be triggered.
Connect
On
Demand
Redial Interval
Router will automatically re-dial with this interval when it fails
communicating to peer via TCP or UDP.
30
Max Retries
The maximum retries times for automatically re-connect when router fails
to dial up.
After maximum retries, router will reboot the wireless module. If router
still cannot dial up successfully, it will try to switch to the other SIM card.
Then router will re-connect with the other SIM card with maximum retries.
After successful connection, the Max Retries counter will be set to 0.
3
Inactivity Time
Configurable after “Connect On Demand” was selected.
This field specifies the idle time setting for GPRS/3G auto-disconnection
and trying to revert back to preferred SIM card.
0 means timeless.
0
Serial Output Content
The content which output to the serial device which connect to router and
inform it that router is ready to receive serial data.
Null
Triggered by Serial Data
Tick this check box to allow router automatically connects to cellular
network from idle mode when there is data comes out from serial port.
Enable
Triggered by Tel
Tick this check box to allow router automatically connects to cellular
network from idle mode when make a voice call to router.
Disable
Triggered by SMS
Tick this check box to allow router automatically connects to cellular
network from idle mode when send a specific SMS to router.
Disable
SMS Connect Command
Users shall send this specific SMS to trigger router to connect to cellular
network.
Null
SMS Disconnect
Command
Users shall send this specific SMS to trigger router to disconnect to cellular
network.
Null
