• Codabar (without check sum)
• Code 39 (without check sum)
• Code 128,
subset
B
and C (with check sum)
• GTIN (inciuding
JAN) (with check sum)
• Interleaved 2 of
5 (without check sum)
Instrument
Note:
GTIN
and Interleaved
2
of 5 barcode types are not
enabled
by
default. 1f
you require these barcode types,
contact
Roche Service.
Supported
characters
SP!#$%&O*.
1234567890:;<=>@ABCDEFGHIJKLM
(Code 128 B and C)
NOPQRTSUVWXYZ\
[]A_’abcdefghijklmnopqrstuvw
xyz{}+
Note:
\
A
& should not be used in any manual entry
field (e.g. specimen barcodes, comments)
Not supporled characters
/,Del
(Code
128 B
and C)
String length
Maximum 20 characters, excluding start,
stop and
check characters. Depends on label length.
For Codabar and Interleaved 2 of 5, the minimum is 4
characters, excluding start, stop, and check characters.
. For all other supported barcode types, the minimum is 2
characters, excluding start, stop, and check characters.
Code density tolerance
Best reading performance with X dimension between
0.19 mm (0.0075 in) and 0.25 mm (0.01 in)
Quiet zone
10 times the X dimension, atleast 3 mm (0.12 in).
Print quality
• Printing with
ANSI
/
CEN
/
ISO grade A or B is
required.
. Suitable for offset,
typographic, intaglio and
flexographic
printing.
. Not suitable for mechanical dot-matrix and thermo
matrix
printing.
Table 3-11 Barcode reader
Interfaces
Item Technical details
User interface
Software running on the software control unit.
Instrument interface
The instrument is connected to the software control unit
through a USB connection.
Place the software control unit close
to
the instrument.
Use the originally delivered USB cable only.
Table 3-12
Interfaces
Waste
Item Technical details
Solid waste
• Small solid waste bag holds used pipetting tips of at
most one full run.
. Large solid waste bag holds used pipetting tips of at
most three full runs.
Liquid waste
Liquid waste container holds liquid waste.
Table 3-13 Waste
