130 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018
Chapter 6 Communicate over Networks
Figure 15 shows a 1769-L27ERM-QBFC1B control system using a star
topology.
Figure 15 - Example 1769-L27ERM-QBFC1B Control System Using a Star Network Topology
Figure 16 shows an example 1769-L33ERM control system using a star
topology.
Figure 16 - Example 1769-L33ERM Control System Using a Star Network Topology
PowerFlex 525
Kinetix 350
1734-AENTR POINT I/O
PanelView Plus
Stratix 6000
1769-L27ERM-QBFC1B
1 (Front)1 (Front)1 (Front)
2 (Rear)
00:00:BC:2E:69:F6
1
2
34
56
78
Kinetix 6500
PowerFlex 525
1734-AENTR POINT I/O
PanelView Plus
Stratix 6000
1769-L33ERM
