Rockwell Automation Publication 1769-UM021I-EN-P - May 2018 135
Communicate over Networks Chapter 6
Figure 17 shows an example 1769-L27ERM-QBFC1B control system using a
DeviceNet network.
Figure 17 - Example 1769-L24ER-QB1B Control System Using a DeviceNet Network
Figure 18 shows an example 1769-L33ERM using a DeviceNet network.
Figure 18 - Example 1769-L33ERM Control System Using a DeviceNet Network
• 1769-L24ER-QB1B
• 1769-SDN Scanner
1606-XLDNET
DeviceNet Connection
E3™ Electronic
Overload Relay
• 1734-ADN POINT I/O
•POINT I/O
• 1769-L24ER-QB1B
• 1769-SDN Scanner
1606-XLDNET
DeviceNet Connection
E3 Electronic
Overload Relay
• 1734-ADN POINT I/O
•POINT I/O
