37 Publication 1794-UM066B-EN-E - March 2015
Chapter
5
Analog I/O with Direct Connection
Overview
In this example you add analog input and output modules to the FLEX I/O
configured with two digital I/O modules in the previous chapter. Analog
modules default to direct connection, so you will open a direct connection to
each analog module while still using a single rack optimized connection for the
two digital I/O modules.
To test the system, the example of the previous chapter is modified to send a
signal to one of the analog output channels and read the signal back in through
one of the analog input channels.
Set Up the Hardware
Change the system hardware setup of the previous chapter to that shown below,
adding the FLEX analog input and output modules to the DIN rail with the
1794-AENTR adapter and digital I/O modules.
Topic Page
Set Up the Hardware 37
Create the Example Application 38
Add the Analog Modules to the I/O Configuration 39
Add the Analog Input Module to the I/O Configuration 39
Add the Analog Output Module to the I/O Configuration 42
Edit the Controller Tags 45
Modify the Ladder Program 47
Download the Program 47
Test the Example Application 48
