Rockwell Automation Allen-Bradley 1794-AENTR User Manual

57 Publication 1794-UM066B-EN-E - March 2015
Appendix C
Adapter Web Dialogs
Overview
The Web server dialog of the FLEX I/O adapter offers extensive internal and
network diagnostics. To view the Web dialogs, enter the IP address of the
FLEX I/O adapters into your browser.
Work with the Home Page
Use the adapter diagnostics home page to access other adapter diagnostics web
pages and see the following information.
• ModuleName
• Module Description
• Module Location
• IP Address
• Ethernet Address (MAC)
• DHCP Enabled
• Status
• Serial Number
• Product Revision
• Firmware Version Date
To display and work with the adapter diagnostics home page, follow these
procedures.
Topic Page
Work with the Home Page 57
Work with the Diagnostics Pages 59
Use the Diagnostic Overview Page 60
Use the Network Configuration Page 66
Use the Ethernet Statistics Page 62
Use the I/O Connections Page 63
Work with the Configuration Pages 64
Use the Device Identity Page 65
Use the Network Configuration Page 66
Use the Device Services Page 68
IMPORTANT
Make sure that your PC Internet LAN setting and your TCP/IP settings are
configured to access the subnet on which your adapter communicates.
