Publication 1794-UM066B-EN-E - March 2015
Configure the Adapter for Your EtherNet/IP Network 21
Save the Relation List
You can save the Relation List to use later. To save the Relation List do the
following:
1. Select Save As... from the File menu.
The Save As dialog box appears.
2. Select the folder you want to save the list to.
3. Enter a file name for the Relation List (for example, control system
configuration) and click Save.
If you want to see your saved file names in the Open dialog box, save your
files using the default file type (*.bpc).
Configure Your Adapter
using DHCP Software
DHCP (Dynamic Host Configuration Protocol) software automatically assigns
IP addresses to client stations logging onto a TCP/IP network. DHCP is based
on BootP and maintains some backward compatibility. The main difference is
that BootP was designed for manual configuration, while DHCP allows for
