Publication 1794-UM066B-EN-E - March 2015
Analog I/O with Direct Connection 49
4. Monitor channel 0 of the 1794-IF4I input module
(FLEX_IO_Adapter:2.I.Ch0Data above).
The value slowly rises to approximately 32000, resets to zero, starts rising
again, and so on, as the output of the timer is received from the
1794-OF4I output module.
This completes the Direct Connect Analog I/O example.
Chapter Summary
This chapter described how to set up and use analog I/O modules with direct
connection.
For information on wiring and troubleshooting the I/O modules,
refer to the FLEX I/O Analog I/O Module Installation Instructions,
publications 1794-IN037
and 1794-IN038.
