Rockwell Automation Publication 20B-IN017B-EN-P - September 2011 19
Component Diagrams and Torque Specs Chapter 1
Wires Wires to TB2 7 0.8
Wires Wires to TB3 8 – 10 0.9 – 1.1
CT Mounting Plate Mounting Plate to CT Clamping Plate 14 2
CT Clamping Plate Clamping Plate to Bus Bar 26 3
Power Cables Cables to terminals 80 9
Main Control, Gate Driver, Precharge
Board Mounting Plates
Plates to chassis 26 3
High Voltage Guard Guard to chassis 26 3
Component Fastener Application
Torque
lb•in
Torque
N•m
