8 Rockwell Automation Publication 20B-IN017B-EN-P - September 2011
Preface
Recommended Tools
The following list of tools is provided for your reference to disassemble and
assemble the drive and components. This list may not be all-encompassing for
your situation. Not all tools are needed for some components. Refer to pertinent
sections for details.
Description Notes
Torque wrench (metered in lb•in or N-m), T30 and T40 bits
Torque seal or colored marker
Screwdrivers (standard, Phillips, star various sizes)
Magnetic screwdriver, long
Socket set, metric
Cylindrical pick-up magnet
Pliers, regular and needle-nose
Wire cutters
Volt ohm meter Used to test Inverter Snubber Resistors
Isopropyl alcohol
Nylon tie wraps
Pencil
14 or 16 gauge wire, about 10 cm (4 in.) Needed whenever IGBT gates are exposed. Used to
short the gates.
Two (2) #10 wire lugs, either fork or ring
