Rockwell Automation Publication 20B-IN017B-EN-P - September 2011 7
Preface
Introduction
This publication provides guidelines for replacing the major components in the
PowerFlex 700 Frame 7 drive.
Component Kits
All kits include necessary components, ESD wrist strap and hardware (if
required), and thermal grease (if required).
Refer to the master parts list for the most up-to-date information:
http://www.ab.com/support/abdrives/powerflex70/PF7ReleasedParts.pdf
Description Kit Catalog No. Notes
Precharge Board SK-G9-PRE1-V480 AC input
1336-PB-SP22C DC input
Main Control Board SK-G9-VMCB1-D0 115V I/O
SK-G9-VMCB1-C0 24V I/O
T-Comm Board SK-G9-TCOMM
Switch Mode Power Supply Board SK-G9-PWRS1-D0
Power Interface Board SK-G9-GDB1-D292 292A Drives
SK-G9-GDB1-D325 325A Drives
Heatsink Fan SK-G1-FAN1-F7
Heatsink Fan Transformer 1336-T-SP5A 480 to 120 Auto transformer (fan only)
Current Transducer SK-G1-CT1-F7 Includes one Transducer.
Inverter Power Module (IGBT) SK-G1-QOUT1-F7 Includes
·Two IGBTs.
·Two Gate Interface Boards.
Inverter Snubber Kit SK-G1-INVSNB1-F7 Includes:
·One Snubber Board.
·One Resistor.
SCR Snubber Kit SK-G1-SCRSNUBRB AC input requires three kits.
DC input requires one kit.
Converter Power Module (SCR) SK-G1-SCR1-F7 AC input.
Kit includes three SCR Modules.
DC Precharge SCR Module SK-G1-SCR2-F7 DC input.
Kit includes one SCR Module
Thermal Sensors SK-G1-THM1-F7 Includes:
·Main Control Panel Thermal Sensor
·Heatsink Thermal Sensor.
Bus Fuse 1336-F1-SP6A
Bus Capacitor SK-G1-BUSCAP1-F7 Includes one Capacitor.
MOV SK-G1-MOV1-F7 AC input.
DC Link Choke SK-G1-DCCHOKE1-F7 AC input.
Balancing Resistor 1336-RLOAD-SP4A Includes one Resistor.
