Page #64 background imageLoading...
Page #64 background image
64 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
309 % Motor Flux
Displays the motor flux in % of nominal.
Default:
Min/Max:
Units:
Scale:
0.0
0.0/100.0
%
100 = 4096
RO 16-bit
Integer
310 Output Freq
Displays the motor stator frequency.
Default:
Min/Max:
Units:
0.00
-/+250.00
Hz
RO Real
311 Output Power
Motor Power is the calculated product of the torque reference and motor speed feedback. A 125ms filter is
applied to this result. Positive values indicate motoring power; negative values indicate regenerative power.
Note: The units were changed from kW to Hp for firmware version 2.003.
Default:
Min/Max:
Units:
0.00
-/+9999.00
Hp
RO Real
312 MotorFluxCurr FB
Displays the measured per unit motor flux producing current.
Default:
Min/Max:
Units:
0.0000
0.0000/1.0000
P. U .
RO Real
313 Heatsink Temp
Displays the measured temperature of the drive's heatsink.
Default:
Min/Max:
Units:
0.0000
-30.0000/200.0000
°C
RO Real
314 VPL Firmware Rev
Displays the major and minor revision levels of the drive's Velocity Position Loop (VPL) software.
Notes: The default value was changed from 1.11 to 2.003 for firmware version 2.003. The default value was
changed from 2.003 to 3.001 for firmware version 3.001. Changed all values to three decimal places for firmware
version 4.001.
Default:
Min/Max:
Scale:
1.003
0.001/99.999
000
RO 16-bit
Integer
315 VPL Build Number
Displays the build number of the drive's Velocity Position Loop (VPL) software.
Note: The default value was changed from 8001 to 1 for firmware version 2.003.
Default:
Min/Max:
1
1/10000
RO 16-bit
Integer
316 SynchLink Status
Indicates status of SynchLink™ functions.
Bit 0 “FB Opt Prsnt” indicates the presence of an optional feedback daughter card.
Bit 1 “Encdr0 Prsnt” indicates the presence of encoder 0.
Bit 2 “Encdr1 Prsnt” indicates the presence of encoder 1.
Bit 3 “In Sync” indicates SynchLink communications is synchronized.
Bit 4 “Tx Active” indicates TX frames are being transmitted downstream from this node.
Bit 5 “Rx Active” indicates RX frames are being received from nodes upstream.
Bit 15 “Rx Data Enbl” indicates received data is being updated.
Note: Bit 8 “Open Wire” was changed to “Reserved”, and bit 12 “SOB Present” and bit 14 “Reset Req’d” were added for firmware 2.004.
Refer to the SynchLink System Design Guide, publication 1756-TD008, for more information.
317 SL System Time
Displays the SynchLink system time counter.
Default:
Min/Max:
Units:
0
0/1048575
μs
RO 32-bit
Integer
318 Posit Spd Output
Final output of the position regulator.
Default:
Min/Max:
Units:
Scale:
0.0000
-/+14112.0000
rpm
Par 4 [Motor NP RPM] = 1.0 P.U.
RO Real
319 Selected Trq Ref
Displays the actual selected torque reference value after Par 110 [Speed/TorqueMode].
Default:
Min/Max:
Units:
0.0
-/+8.0 P.U.
P. U .
RO Real
320 Exception Event1
Indicates the presence of certain drive anomalies. In some cases, you may configure the drive's response to these events by entering values in the parameters of the fault/alarm configuration group
of the utility file.
No. Name
Description
Values
Linkable
Read-Write
Data Type
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Rx Data Enbl
Reset Req'd
Reserved
SOB Present
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Rx Active
Tx Active
In Sync
Encdr1 Prsnt
Encdr0 Prsnt
FB Opt Prsnt
Default xxxxxxxxxxxxxxxx00x0xxxxxx000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
PWM Asynchro
Precharge Er
MC Firmware
PWM Short
VPL/MC Comm
OverCurrent
Ground Fault
Trans Desat
Bus OverVolt
MC Commissn
Over Freq
Inertia Test
DSP Error
DSP Mem Err
Ext Fault In
Inv OL Trip
Inv OL Pend
Inv TempTrip
Inv TempPend
Motor Stall
Mtr OL Pend
Mtr OL Trip
Power Loss
SLink Comm
SLink HW
Ctrl EE Mem
FB Opt1 Loss
FB Opt0 Loss
Encdr1 Loss
Encdr0 Loss
SpdRef Decel
Abs OverSpd
Default 00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
