332 700L EventStatus
Indicates the presence of certain drive anomalies for PowerFlex 700L (LiquiFlo) drive.
• Bit 0 “Dsat Phs U1” indicates that the primary structure detected a Dsat on phase U.
• Bit 1 “Dsat Phs V1” indicates that the primary structure detected a Dsat on phase V.
• Bit 2 “Dsat Phs W” indicates that the primary structure detected a Dsat on phase W.
• Bit 3 “Ovr Current1” indicates that the primary structure detected an over current.
• Bit 4 “Ovr Volt1” indicates that the primary structure detected an over voltage.
• Bit 5 “Asym DcLink1” indicates that the primary structure detected an unbalanced DC Link.
• Bit 6 “Pwr Suply1” indicates that the primary structure detected a power supply failure.
• Bit 7 “HW Disable1” indicates that the primary structure detected a hardware disable.
• Bit 8 “Latch Err1” indicates that the primary structure fault was generated but no indicating bit was set.
• Bit 14 “Cnv NotLogin” the converter was expected but none logged in.
• Bit 15 “Cnv NotStart” the converter was commanded to start but did not become active.
• Bit 16 “Dsat Phs U2” the second structure detected a Dsat on phase U.
• Bit 17 “Dsat Phs V2” the second structure detected a Dsat on phase V.
• Bit 18 “Dsat Phs W2” the second structure detected a Dsat on phase W.
• Bit 19 “Ovr Current2” the second structure detected an over current.
• Bit 20 “Ovr Volt2” the second structure detected an over voltage.
• Bit 21 “Asym DcLink2” the second structure detected an unbalanced DC Link.
• Bit 22 “Pwr Suply2” the second structure detected a power supply failure.
• Bit 23 “HW Disable2” the second structure detected a hardware disable.
• Bit 24 “Latch Err2” the second structure fault was generated but no indicating bit was set.
Note: This parameter was added for firmware version 2.003.
333 700L FaultStatus
Indicates the occurrence of exception events that have been configured as fault conditions for PowerFlex 700L (LiquiFlo) drive.
• Bit 0 “Dsat Phs U1” indicates that the primary structure detected a Dsat on phase U.
• Bit 1 “Dsat Phs V1” indicates that the primary structure detected a Dsat on phase V.
• Bit 2 “Dsat Phs W” indicates that the primary structure detected a Dsat on phase W.
• Bit 3 “Ovr Current1” indicates that the primary structure detected an over current.
• Bit 4 “Ovr Volt1” indicates that the primary structure detected an over voltage.
• Bit 5 “Asym DcLink1” indicates that the primary structure detected an unbalanced DC Link.
• Bit 6 “Pwr Suply1” indicates that the primary structure detected a power supply failure.
• Bit 7 “HW Disable1” indicates that the primary structure detected a hardware disable.
• Bit 8 “Latch Err1” indicates that the primary structure fault was generated but no indicating bit was set.
• Bit 14 “Cnv NotLogin” indicates that the converter expected but none logged in.
• Bit 15 “Cnv NotStart” indicates that the converter commanded to start but did not become active.
• Bit 16 “Dsat Phs U2” indicates that the second structure detected a Dsat on phase U.
• Bit 17 “Dsat Phs V2” indicates that the second structure detected a Dsat on phase V.
• Bit 18 “Dsat Phs W2” indicates that the second structure detected a Dsat on phase W.
• Bit 19 “Ovr Current2” indicates that the second structure detected an over current.
• Bit 20 “Ovr Volt2” indicates that the second structure detected an over voltage.
• Bit 21 “Asym DcLink2” indicates that the second structure detected an unbalanced DC Link.
• Bit 22 “Pwr Suply2” indicates that the second structure detected a power supply failure.
• Bit 23 “HW Disable2” indicates that the second structure detected a hardware disable.
• Bit 24 “Latch Err2” indicates that the second structure fault was generated but no indicating bit was set.
Note: This parameter was added for firmware version 2.003.
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Latch Err2 HW Disable2 Pwr Suply2 Asym DcLink2 Ovr Volt2 Ovr Current2 Dsat Phs W2 Dsat Phs V2 Dsat Phs U2 Cnv NotStart Cnv NotLogin Reserved Reserved Reserved Reserved Reserved Latch Err1 HW Disable1 Pwr Suply1 Asym DcLink1 Ovr Volt1 Ovr Current1 Dsat Phs W1 Dsat Phs V1 Dsat Phs U1
Default xxxxxxx00000000000xxxxx000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Latch Err2 HW Disable2 Pwr Suply2 Asym DcLink2 Ovr Volt2 Ovr Current2 Dsat Phs W2 Dsat Phs V2 Dsat Phs U2 Cnv NotStart Cnv NotLogin Reserved Reserved Reserved Reserved Reserved Latch Err1 HW Disable1 Pwr Suply1 Asym DcLink1 Ovr Volt1 Ovr Current1 Dsat Phs W1 Dsat Phs V1 Dsat Phs U1
Default xxxxxxx00000000000xxxxx000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
