112 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 5 Service and Maintenance
Table 20 - Frame 8 Configured Input Bay and Configured Output Bay Replaceable Parts
Schematic
Symbol
Part Description Supplier
Supplier Catalog
Number
Location of Replacement Procedure or Other
Information Relevant to Replacement
CB1
Main Circuit Breaker See Input Power Circuit Breakers on page 105
• For 140G-K circuit breakers, see publication
140G-IN128.
• For 14G-M, or 140GM-M circuit breakers, see
publication 140G-IN042
.
• For 140G-N, 140G-NS, or 140G-R circuit
breakers, see publication 140G-IN068
.
N Frame Main Circuit Breaker's Lugs Rockwell Automation 140G-N-TLA43 Publication 140G-IN064
N Frame Main Circuit Breaker's Handle Mechanism Rockwell Automation 140G-N-RVM21B Publication 140G-IN054
N Frame Main Circuit Breaker's Phase Barriers Rockwell Automation 140G-N-TLA43 Publication 140G-IN064
FU1, FU2, FU3 Main Power Fuse See Input Power Fuses on page 102 —
FU4, FU5, FU6 Voltage Vision Fuse See Control Fuses on page 102
—
FU7, FU8 Control Transformer Primary Fuses See Control Fuses on page 102
—
FU9, FU10 Control Transformer Secondary Fuse See Control Fuses on page 102
—
PWS1 Control Power Supply, 240 W, 24V DC, 10 A Rockwell Automation 1606-XLE240E Publication 1606-IN039
UPS1 Uninterruptible Power Supply, 240 W, 24V DC Rockwell Automation 1606-XLS240-UPS Publication 1606-IN025
BAT1 Battery Module, 12V DC, 7Ah Rockwell Automation 1606-XLSBATASSY1W Publication 1606-IN067
VV1
Voltage Vision Grace Technologies R-3W —
Voltage Vision Label Grace Technologies R-3W-L —
3 Pole Control Fuse Holder Rockwell Automation 1492-FB3C30
1492-FB Fuse Holder with 3 poles product
summary
IRW IR viewing window Hoffman IW3000 —
T1 Control Circuit Transformer, 1600VA, 480V/120V Rockwell Automation 1497-L-BASX-0-N
Control Circuit Transformers Technical Data,
publication 1497-TD001
FAN3 Input Bay Door Fan, 115VAC, 135CFM, W/FLTR Rittal 3241110 IP21/IP54 Door Fan/Vent Assembly on page 117
FAN3 Input Bay Door Fan Filter Media Rittal 3172100 IP21/IP54 Door Vent Filter Media on page 122
FAN4, FAN5 Output Bay Door Fan, 115VAC, 529CFM, W/FLTR Rittal 3245510 IP21/IP54 Door Fan/Vent Assembly on page 117
FAN4, FAN5 Output Bay Door Fan Filter Media Rittal 3173100 IP21/IP54 Door Vent Filter Media on page 122
—
(1)
Roof Vent Filter for Input Bay with Input Protection Rockwell Automation SK-RM-IBFAN-54FLTR1
IP21/IP54 Small Roof Vent Filter Media on
page 123
—
(1)
Input Bay Door Vent - only used on control-only input
bay, no fan included in this assembly
Rittal 3240200 IP21/IP54 Door Vent on page 121
—
(1)
Input Bay Door Vent Filter Media Rittal 3172100 IP21/IP54 Door Vent Filter Media on page 122
—
(1)
Output Bay Door Vent - only used on output bay with
contactor only, no fan include in this assembly
Rittal 3243200 IP21/IP54 Door Vent on page 121
—
(1)
Output Bay Door Vent Filter Media Rittal 3173100 IP21/IP54 Door Vent Filter Media on page 122
LT1
30 mm Pilot Light, White light-emitting diode (LED), 12-
130V AC/DC
Rockwell Automation 800T-QH2W
800T Standard, Push-To-Test, Dual Input
product summary
LT2 30 mm Pilot Light, Green LED, 12-130V AC/DC Rockwell Automation 800T-QH2G
800T Standard, Push-To-Test, Dual Input
product summary
LT3 30 mm Pilot Light, Red LED, 12-130V AC/DC Rockwell Automation 800T-QH2R
800T Standard, Push-To-Test, Dual Input
product summary
POT1 30 mm Potentiometer, 10 KΩ Rockwell Automation 800TC-U29
• 30 mm Push Button Specifications Technical
Data, publication 800-TD009
• 800T Potentiometer Units product summary
SS1 30 mm Selector Switch, Hand-Off-Auto Rockwell Automation 800TC-J17H
800T 3 Position, Knob/Wing Lever product
summary
PB1 30 mm Momentary Push Button, N.O., Green Rockwell Automation 800TC-A1A
800T Momentary Contact, Non-Illuminated
product summary
PB2 30 mm Momentary Push Button, N.C., Red Rockwell Automation 800TC-A6A
800T Momentary Contact, Non-Illuminated
product summary
PB3 30 mm Push-Pull Type, Jumbo Mushroom Head, Red Rockwell Automation 800TC-FXJ6B
800T 2 Position Push-Pull and Push-Pull/Twist
Release product summary
To Next Page
