Rockwell Automation Allen-Bradley PowerFlex 755T

Rockwell Automation Publication 750-IN118A-EN-P - May 2021 113
Chapter 5 Service and Maintenance
Schematic
Symbol
Part Description Supplier
Supplier Catalog
Number
Location of Replacement Procedure or Other
Information Relevant to Replacement
DR1 I/O 24V Digital I/O card Rockwell Automation 20-750-2262C-2R
PowerFlex 750-Series I/O, Feedback, and Power
Option Modules Installation Instructions,
publication 750-IN111
CR1,CR2
24V DC GP Tall Square Base Relay Rockwell Automation 700-HB33Z24
Relay and Time Specifications Technical Data,
publication 700-TD552
11-Blade Socket Rockwell Automation 700-HN153
Surge Suppressor Rockwell Automation 700-AR1
700HB/HJ Relay Retainer Clip Pack Rockwell Automation 700-HN158
TB1,TB2,TB3
4 square mm Double Level Terminal Block Rockwell Automation 1492-JD4 Publication 1492-TD015
IEC End Barrier, 1.5 x 53.9 x 60 mm Rockwell Automation 1492-EBJD4
1492 Terminal Block Accessories End Barrier
product summary
IEC Terminal Block 3 x 80 x 63 mm Partition Plate Rockwell Automation 1492-PPJD3
Terminal Block Specifications Technical Data,
publication 1492-TD015
IEC End Anchor, 8 x 56 x 47 mm Rockwell Automation 1492-EAJ35
1492 Terminal Block Accessories End Anchor
product summary
IEC Center Jumper, 2 PL 6 mm, Plug-In Rockwell Automation 1492-CJLJ6-2
Terminal Block Specifications Technical Data,
publication 1492-TD015
IEC Center Jumper, 3 PL 6 mm, Plug-In Rockwell Automation 1492-CJLJ6-3
IEC Center Jumper, 4 PL 6 mm, Plug-In Rockwell Automation 1492-CJLJ6-4
IEC 35 mm x 7.5 mm x 1 m DIN Rail Rockwell Automation 199-DR1
DIN Mounting Rail, Zinc-plated, Chromated Steel
product summary
IEC 6 x 5 mm Marker Card Rockwell Automation 1492-M6X5
1492 Terminal Block Accessories Snap-In
Individual Marker Card product summary
TB1G Grounding Terminal Block Rockwell Automation 1492-JDG4C
Terminal Block Specifications Technical Data,
publication 1492-TD015
PLUG1
Output Bay Plug, 4 pole, Plug Phoenix Contacts 1788554 —
Output Bay Plug, 4 pole, Socket Phoenix Contacts 1757035 —
PLUG2
Output Bay Plug, 8 pole, Plug Phoenix Contacts 1788596 —
Output Bay Plug, 8 pole, Socket Phoenix Contacts 1757077 —
TAS1, TAS2 Thermostat, SPST, NC, Open 150F, Close 130F Sensata 4344-198-107 —
XR1 Sine-wave Filter Reactor TCI KTRMG750A —
CAP1 Sine-wave Filter Capacitor Bank TCI KPCUL058A64 —
M1 Output Contactor, 750 A Rockwell Automation 100-E750ED11
• IEC Contactor Specifications Technical Data,
publication 100-TD013
• 100-E MCS-E Contactor product summary
M1 Output Contactor Lugs, 750 A Rockwell Automation 100-ETL750 Publication 100-IN073
(1) Not an electrical component, not identified in electrical schematics.
Table 20 - Frame 8 Configured Input Bay and Configured Output Bay Replaceable Parts (Continued)
