114 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 5 Service and Maintenance
Table 21 - Frame 9 Configured Input Bay and Configured Output Bay Replaceable Parts
Schematic
Symbol
Part Description Manufacturer
Manufacturer Catalog
Number
Location of Replacement Procedure or Other
Information Relevant to Replacement
CB1
Main Circuit Breaker See Input Power Circuit Breakers on page 105
• For 140G-K circuit breakers, see publication
140G-IN128.
• For 14G-M, or 140GM-M circuit breakers, see
publication 140G-IN042
.
• For 140G-N, 140G-NS, or 140G-R circuit
breakers, see publication 140G-IN068
.
R Frame Main Circuit Breaker's Lugs Rockwell Automation 140G-R-TLC63 Publication 140G-IN119
R Frame Main Circuit Breaker's Phase Barriers Rockwell Automation 140G-R-PB3H Publication 140G-IN015
R Frame Main Circuit Breaker's Padlock provision ABB KE6PDEHD9 —
R Frame Window Kit Hoffman APWK1612H —
FU1, FU2, FU3 Main Power Fuse See Input Power Fuses on page 102 —
FU4, FU5, FU6 Voltage Vision Fuse See Control Fuses on page 102
—
FU7, FU8 Control Transformer Primary Fuses See Control Fuses on page 102
—
FU9, FU10 Control Transformer Secondary Fuse See Control Fuses on page 102
—
PWS1 Control Power Supply, 480 W, 24V DC, 10 A Rockwell Automation 1606-XLE480EP Publication 1606-IN047
UPS1 Uninterruptible Power Supply, 480 W, 24V DC Rockwell Automation 1606-XLS480-UPS
Switched Mode Power Supply Specifications
Technical Data, publication 1606-TD002
BAT1 Battery Module, 24V DC, 7Ah Rockwell Automation 1606-XLSBATASSY3 Publication 1606-IN068
VV1
Voltage Vision Grace Technologies R-3W —
Voltage Vision Label Grace Technologies R-3W-L —
3 Pole Control Fuse Holder Rockwell Automation 1492-FB3C30
1492-FB Fuse Holder with 3 poles product
summary
IRW IR viewing window Hoffman IW3000 —
T1 Control Circuit Transformer, 1600VA, 480V/120V Rockwell Automation 1497-L-BASX-0-N
Control Circuit Transformers Technical Data,
publication 1497-TD001
FAN3
Input Bay Door Fan, 115VAC, 529 CFM, W/FLTR Rittal 3245510 IP21/IP54 Door Fan/Vent Assembly on page 117
Input Bay Door Fan Filter Media Rittal 3173100 IP21/IP54 Door Vent Filter Media on page 122
FAN4, FAN5,
FAN6, FAN7,
FAN8, FAN9,
FAN10, FAN11
Output Bay Sine-wave Filter Reactor Cooling Fan Mechatronics UF16FC12-BTHR
Sine-wave Filter Reactor Cooling Fan on
page 125
Fingersafe Guard for Sine-wave Filter Reactor Cooling
Fan
Mechatronics MG-16 —
FAN12
Wire Exit Bay Door Fan, 115VAC, 135CFM, W/FLTR Rittal 3241110 IP21/IP54 Door Fan/Vent Assembly on page 117
Wire Exit Bay Door Fan Filter Media Rittal 3240200 IP21/IP54 Door Vent Filter Media on page 122
—
(1)
Three-front-vents Exhaust Hood Vent - one of the
three vents, houses filter media, included on a frame 9
configured input bay with circuit breaker and top
entry
Rittal 3238200
Use the same replacement procedure as IP21/
IP54 Door Vent on page 121. The exhaust hood
vents are a different size, but the steps are the
same.
—
(1)
Three-front-vents Exhaust Hood Vent Filter Media Rittal 3238066
Use the same replacement procedure as IP21/
IP54 Door Vent Filter Media on page 122. The
exhaust hood filters are a different size, but the
steps are the same.
—
(1)
Roof Vent Filter Media Rockwell Automation SK-RM-PBFAN-54FLTR1 IP54 Large Roof Vent Filter Media on page 124
—
(1)
Input Bay Door Vent - only used on control-only input
bay, no fan included in this assembly
Rittal 3240200 IP21/IP54 Door Vent on page 121
—
(1)
Input Bay Door Vent Filter Media Rittal 3172100 IP21/IP54 Door Vent Filter Media on page 122
—
(1)
Output Bay Door Vent - only used on output bay with
contactor only, no fan include in this assembly
Rittal 3243200 IP21/IP54 Door Vent on page 121
—
(1)
Output Bay Door Vent Filter Media Rittal 3173100 IP21/IP54 Door Vent Filter Media on page 122
LT1 30 mm Pilot Light, White LED, 12-130V AC/DC Rockwell Automation 800T-QH2W
800T Standard, Push-To-Test, Dual Input
product summary
LT2 30 mm Pilot Light, Green LED, 12-130V AC/DC Rockwell Automation 800T-QH2G
800T Standard, Push-To-Test, Dual Input
product summary
LT3 30 mm Pilot Light, Red LED, 12-130V AC/DC Rockwell Automation 800T-QH2R
800T Standard, Push-To-Test, Dual Input
product summary
