42 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 2 Prepare for Installation
Follow the installation instructions that come with the base system. For a list of
base system components that can be used with the PowerFlex 755T Drives
Configured to Order Program, see Table 2
.
Table 2 - Rittal Base System Components
Components
Height of Bottom of Bay
Off of Mounting Surface
mm (in.)
Length of Side of Bay
Component is Used With
(1)
mm (in.)
(1) The trim panels along the sides of the bay are not the full length of the side of the bay they are used for
because part of that length can be covered by corner panels over the corner bases.
Corner base (required for base/
plinth system)
100 (4.0) —
200 (8.0) —
Trim panels for between adjacent
corner bases where bays are
joined (optional)
100 (4.0) —
200 (8.0) —
Trim panels to cover the corner
bases (optional)
100 (4.0) —
200 (8.0) —
Trim panels for front, back, and
sides of bay (optional)
100 (4.0)
300 (11.8)
400 (15.7)
600 (23.6)
(2)
(2) All bays in the PowerFlex 755T Drives Configured to Order Program use the 600 mm (23.6 in.) side length
panels for the sides of the bay.
800 (31.5)
1000 (39.4)
200 (8.0)
300 (11.8)
400 (15.7)
600 (23.6)
(2)
800 (31.5)
1000 (39.4)
