Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

66 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 3 Mechanical and Electrical Installation
Figure 58 - Frame 8 Configured Input Bay
Control-only: Internal Components
Item Description
1 Terminal blocks
2Fuse blocks
3 Control relays
4 Control power supply (24V DC)
5 Uninterruptible power supply, and battery (behind control power supply)
6 Control transformer
7 PE ground bar with ground clamps included
5
6
4
1
2
3
7
