Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

Rockwell Automation Publication 750-IN118A-EN-P - May 2021 71
Chapter 3 Mechanical and Electrical Installation
Figure 63 - Frame 8 Configured Input Bay Top Entry Control Panel Figure 64 - Frame 8 Configured Input Bay Bottom Entry Control Panels
Item Description (for top and bottom entry control panels)
1 Terminal blocks
2Fuse blocks
3 Control relays
4 Control power supply (24V DC)
5 Uninterruptible power supply
6 Battery
7
Control transformer (on bottom entry control panel but not top entry
control panel)
1
2
3
4
5
6
1
2
6
7
3
4
5
