Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

92 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 3 Mechanical and Electrical Installation
Figure 91 - Frame 9 Configured Bay Control Connector Wire Route from Drive Power Bay to Configured
Output Bay
1
2
Item Description
1 Cutout for routing configured bay control wires out of the drive power bay
2 Cutout for routing configured bay control wires into the configured output bay
