Rockwell Automation Publication 750-IN118A-EN-P - May 2021 91
Chapter 3 Mechanical and Electrical Installation
Figure 90 - Configured Bay Control Connections on the Frame 9 Configured Output Bay
2
3
1
4
Item Identification Description
1 PLUG3 Four-pole socket connector 24V DC
2 PLUG3 Four-pole plug connector 24V DC. Must connect to item 1 during installation.
3 PLUG4 Four-pole socket connector 120V AC
4 PLUG4 Four-pole plug connector 120V AC. Must connect to item 3 during installation.
