Rockwell Automation CENTERLINE 2100

Publication 2100-IN012C-EN-P - April 2009 29
Installation Procedures Chapter 2
Mounting Dimensions for 25 in. Wide Section with 9 in. (228.6 mm) Wireway [90 in.
(2286 mm) high]
The optional external mounting channels add 1.5 in. (38.1 mm) to the
height.
