Roland RD-700NX User Manual

27
Performance
Performing with a Variety of Live Sets
The RD-700NX comes with a many built-in Sounds.
Each one of these individual sounds is called a “Live Set.”
Live Sets are assigned to the LIVE SET buttons according to the tone category selected.
Each category has several variations.
Try selecting and performing with a number of di erent Live Sets.
13
2
1. Press the BANK [PRESET] button or the BANK [USER] button to select the bank.
The indicator of the selected button will light.
2. Press any of the LIVE SET buttons to select the category.
The indicator of the selected LIVE SET button will light.
3. Use the [DEC] [INC] buttons or VALUE dial to select the tone.
Play the keyboard, and you will hear the selected Live Set.
NOTE
When you edit a setting, an “*” will appear.
If you turn o the power or select a di erent Live Set when an “*” is shown in the display, the setting changes you’ve made will be discarded. If you
want to keep the settings, save the Live Set (p. 45).

Roland RD-700NX Specifications

Power

power consumption	12 W

Audio and Sound

maximum polyphony	128 voices
sound generator	SuperNATURAL Piano, SuperNATURAL (E.Piano), Virtual Tone Wheel Organ, PCM Sound Generator, GM2 (for SMF Playback)
effects	Multi-Effects (2 x 4 systems, 84 types), Reverb (6 types), Chorus (3 types), 3-band Compressor, 4-band Digital Equalizer

Connectivity

output jacks	L/MONO, R Jacks (1/4-inch phone type), BALANCED OUT (L, R) Jacks (XLR type)
pedal jacks	DAMPER Pedal Jack, Control Pedal Jacks (FC1, FC2)
midi connectors	IN, OUT1, OUT2, THRU/OUT3

Weight and Dimensions

width	1, 444 mm (56-7/8 inches)
depth	375 mm (14-13/16 inches)
height	148 mm (5-7/8 inches)
weight	25.0 kg (55 lbs 2 oz)
