Using the Convenient Functions in Performances
Changing the Undulation of the Organ Tone (Rotary Eect)
While the Tone Wheel screen is displayed, you can change the undulation rate of the Rotary eect with the Pitch Bend lever.
The Rotary eect is an eect that recreates the sound of the rotating speakers used to augment the sound of an organ.
Moving the pitch bend lever to left or right will toggle the Rotary eect between fast and slow regardless of the direction in which you move the lever.
MEMO
This Pitch Bend Lever setting is eective only in the Tone Wheel screen.
Changing the Layer LEVEL Slider Feet Assignments
You can change the Feet assigned to each of the Layer LEVEL sliders used in Tone Wheel mode.
1. Press the [MENU] button, getting the indicator to light.
The Edit Menu screen appears.
2. Press the Cursor [ ] [ ] buttons to select “2.Control.”
3. Press the [ENTER] button to display the Edit screen.
4. Press the Cursor [
] [ ] buttons to select “Harmonic Bar.”
Footage assignments in the Tone Wheel screen (from the left of the screen)
16
’ 5-1/3’ 8’ 4’ 2-2/3’ 2’ 1-3/5’ 1-1/3’ 1’
5. Press the Cursor [ ] [ ] buttons to move the cursor to the parameter for changing the Feet.
“LED ON” and “LED OFF” in the screen indicate whether Layer switch is switched on or o.
Parameter Value
UP 1 (UPPER 1)
16’, 5-1/3’, 8’, 4’, 2-2/3’, 2’, 1-3/5’, 1-1/3’, 1’
UP 2 (UPPER 2)
LW 1 (LOWER 1)
LW 2 (LOWER 2)
6. Use the [DEC] [INC] buttons or the VALUE dial to select the Feet.
7. When you have nished making the settings, press the [MENU] button, extinguishing its indicator.
You are returned to the Live Set screen.
