Roland RD-700NX User Manual

30
Performance
Changing the Tone for a Layer
1 2
3
3
1. Press the [Layer EDIT] button to access the layer edit screen.
2. Use the Cursor [
] [ ] buttons to select the layer whose tone you want to change.
Layers that have their Layer switch turned o are dimmed in the screen.
3. Use the LIVE SET buttons to select the tone category, and then use the [DEC] [INC] buttons or
the VALUE dial to select a tone.
MEMO
If you use the [ ] [ ] buttons to select a layer whose Layer switch is o (unlit), the Layer switch of the selected layer will blink. If you then press
the blinking button, that layer’s Layer switch will turn on (lit).

Roland RD-700NX Specifications

Power

power consumption	12 W

Audio and Sound

maximum polyphony	128 voices
sound generator	SuperNATURAL Piano, SuperNATURAL (E.Piano), Virtual Tone Wheel Organ, PCM Sound Generator, GM2 (for SMF Playback)
effects	Multi-Effects (2 x 4 systems, 84 types), Reverb (6 types), Chorus (3 types), 3-band Compressor, 4-band Digital Equalizer

Connectivity

output jacks	L/MONO, R Jacks (1/4-inch phone type), BALANCED OUT (L, R) Jacks (XLR type)
pedal jacks	DAMPER Pedal Jack, Control Pedal Jacks (FC1, FC2)
midi connectors	IN, OUT1, OUT2, THRU/OUT3

Weight and Dimensions

width	1, 444 mm (56-7/8 inches)
depth	375 mm (14-13/16 inches)
height	148 mm (5-7/8 inches)
weight	25.0 kg (55 lbs 2 oz)
