Roland Sound Canvas SC-8850 User Manual

147
Appendices
<Example> Setting the Part 11 to a Drum Part (Room Set).
F0 41 10 42 12 40 1A 15 02 0F F7
MIDI CH = 11
CC#00 000
CC#32 4
PC# 009
[General MIDI 2] Use bank select LSB and program change.
Bank select MSB is 121. Use 120 to set as the drum part.
<Example> Setting the Part 11 to a Drum Part (Room Set).
MIDI CH = 11
CC#00 120
CC#32 0
PC# 009
* The General MIDI 2 sound map differs from the GS format. The SC-8850 will normally operate in the
GS format, but if a GM2 System On message is received, it will enter General MIDI 2 mode, and will
use the special sound map. In this state, it will not be possible to select the SC-8850’s own sounds.
Items newly defined in General MIDI 2
• Polyphony 32(General MIDI 1 is 24)
• Number of sounds 256 sounds / 9 drum sets (General MIDI 1 is 128 sounds / 1 drum set)
• Messages that must be received (* indicates those added by General MIDI 2)
Note ON/OFF
Program Change
Control Change
Bank Select (Controllers 0 & 32)
Modulation Depth (Controller 1)
Portamento Time* (Controller 5)
Channel Volume (Controller 7)
Pan (Controller 10)
Expression (Controller 11)
Hold 1 (Controller 64)
Portamento ON/OFF* (Controller 65)
Sostenuto* (Controller 66)
Soft* (Controller 67)
Harmonic Content* (Controller 71)
Release Time* (Controller 72)
Attack Time* (Controller 73)
Brightness* (Controller 74)
Decay Time* (Controller 75)
Vibrato Rate* (Controller 76)
Vibrato Depth* (Controller 77)
Vibrato Delay* (Controller 78)
Reverb Send Level* (Controller 91)
Chorus Send Level* (Controller 93)
Data Entry (Controllers 6 & 38)
RPN LSB/MSB (Controller 100 & 101)
RPN
Pitch Bend Sensitivity
Fine Tune
Coarse Tune
Modulation Sensitivity*
RPN Null
General MIDI 2 Sound map
(p.213)
