Roland Sound Canvas SC-8850 User Manual

93
Using Insertion Effects
03: Enhancer [01H, 02H]
The Enhancer controls the overtone structure of the high
frequencies, adding sparkle and tightness to the sound.
fig.9-3
+Sens (Sensitivity) 0–127 [1 (40 03 03)]
Adjusts the sensitivity of the enhancer.
#Mix (Mix Level) 0–127 [2 (40 03 04)]
Adjusts the proportion by which the overtones generated
by the enhancer are combined with the direct sound.
Low Gain -12–+12 [17 (40 03 13)]
Adjusts the gain of the low frequency range.
Hi Gain (High Gain) -12–+12 [18 (40 03 14)]
Adjusts the gain of the high frequency range.
Level (Output Level) 0–127 [20 (40 03 16)]
Adjusts the output level.
04: Humanizer [01H, 03H]
This adds a vowel character to the sound, making it similar
to a human voice.
fig.9-4
Drive 0–127 [1 (40 03 03)]
Adjusts the depth of distortion.
Drive Sw (Drive Switch) Off/On [2 (40 03 04)]
Turns Drive on/off.
+Vowel a/i/u/e/o [3 (40 03 05)]
Selects the vowel.
Accel 0–15 [4 (40 03 06)]
Adjusts the time over which the sound will move to the
specified Vowel. Smaller values will require more time.
Low Gain -12–+12 [17 (40 03 13)]
Adjusts the low frequency gain.
Hi Gain (High Gain) -12–+12 [18 (40 03 14)]
Adjusts the high frequency gain.
Pan (Output Pan) L63–0–R63 [19 (40 03 15)]
Adjusts the stereo position of the output sound. L63 is far
left, 0 is center, and R63 is far right.
#Level (Output Level) 0–127 [20 (40 03 16)]
Adjusts the output volume.
Effects that distort the sound (distortion type)
05: Overdrive [01H, 10H]
This effect creates a soft distortion similar to that produced
by tube amplifiers.
fig.9-5
+Drive 0–127 [1 (40 03 03)]
Adjusts the degree of distortion.
Amp Type (Amp Simulator Type)
Small/BltIn/2-Stk/3-Stk [2 (40 03 04)]
Select the type of guitar amp.
Small: small amp
BltIn: single-unit type amp
2-Stk: large double stack amp
3-Stk: large triple stack amp
Amp Sw (Amp Switch) Off/On [3 (40 03 05)]
Turns the Amp Type on/off.
Low Gain -12–+12 [17 (40 03 13)]
Adjusts the gain of the low frequency range.
Hi Gain (High Gain) -12–+12 [18 (40 03 14)]
Adjusts the gain of the high frequency range.
#Pan (Output Pan) L63–0–R63 [19 (40 03 15)]
Adjusts the stereo location of the output sound. L63 is far
left, 0 is center, and R63 is far right.
Level (Output Level) 0–127 [20 (40 03 16)]
Adjusts the output level.
06: Distortion [01H, 11H]
This effect produces a more intense distortion than
Overdrive.
fig.9-6
+Drive 0–127 [1 (40 03 03)]
Adjusts the degree of distortion.
Amp Type (Amp Simulator Type)
Small/BltIn/2-Stk/3-Stk [2 (40 03 04)]
Selects the type of guitar amp.
Small: small amp
BltIn: single-unit type amp
2-Stk: large double stack amp
3-Stk: large triple stack amp
L
R
Enhancer
Enhancer
Mix
EQ
EQ
L
R
Humanizer
EQ
Pan
Amp
Simulator
EQ
Pan
L
R
Over
drive
Amp
Simulator
EQ
Pan
L
R
Distortion
