19
Connecting to Your Computer/MIDI Keyboard
Connecting to Headphones
Use headphones of 8 – 150 ohms impedance. Sound will be output from the audio
output jacks even when headphones are connected.
fig.1-12e
Connecting to an Audio Input Jacks
You can connect the output jacks of other MIDI sound sources to these jacks. The au-
dio signal that is input here will be mixed with this unit’s sound and output from the
audio output1 jacks.
If the signal input to this unit is too large or too small, use the Audio Input Volume
knob to adjust it. If the input signal is too large, rotate the knob to the left to reduce
the volume.
fig.1-13e
Stereo Headphones
The headphone jack will
output the sound of
OUTPUT1.This means that
the sound of Parts assigned
to OUTPUT2 will not be
heard from the headphone
ack. (p.57)
SC-8850
OUT PUT
INPUT
Audio (Sound Card, CD player etc)
Audio Input Volume knob
To Next Page
