91
Using Insertion Effects
Insertion Effect Types
Effect types can be broadly grouped into the following
categories.
Effects that modify the tone color (filter type) (1–4)
Effects that distort the sound (distortion type) (5–6)
Effects that modulate the sound
(modulation type) (7–13)
Effects that affect the level (compressor type) (14–15)
Effects that broaden the sound (chorus type) (16–20)
Effects that reverberate the sound
(delay/reverb type) (21–28)
Effects that modify the pitch (pitch shift type) (29–30)
Others (31–34)
Effects that connect two types of effect in series
(series 2) (35–46)
Effects that connect three or more types of effect in series
(series 3/series 4/series 5) (47–55)
Effects that connect two types of effect in parallel
(parallel 2) (56–64)
In the explanations that follow, the hexadecimal values used
when making settings via Exclusive messages are given at
the end of the effect type line. The parameter number is
given in decimal form at the end of the Effect Parameter line.
Use these values when you use MIDI messages to set param-
eters. For details on using Exclusive messages, refer to page
131, 233.
< Example >
01: Stereo-EQ [01H, 00H]
This means that the value for Address corresponding to EFX
40H 03H 00H is MSB:01H, LSB:00H.
Low Freq 200/400 [1 (40 03 03)]
[1] describes that it’s the first parameter.
(40 03 03) describes that it’s the parameter’s address for [1].
For example, if you wish to set the effect type to 01:Stereo-EQ
(stereo equalizer) and set Low Freq (low frequency) to 400,
transmit the following Exclusive message.
1. Set the effect type to 1:Stereo-EQ.
fig.stereoEQ
2. Select the Low Freq.
fig.lowFreq
* See the Insertion Effect List on page 216 for the correspondence of
Parameter to Value.
* See page 237 for the correspondence of Parameter number to Address.
* Parameters with + or # symbols allow you to modify their value using a
specified controller, such as pitch bend lever and sliders, or with control
change messages (Modifying the Effect Parameters Using Controllers
p.129).
address
for EFX
Value set for
Stereo EQ
F0 41 10 42 12 40 03 00 01 00 3C F7
address
corresponding to [1]
Value to select
+400
F0 41 10 42 12 40 03 03 01 39 F7
To Next Page
