234
Appendices
Parameter address map
This map indicates address, size, Data (range), Parameter, Description, and Default Value of parameters which can be transferred using Request data 1 (RQ1) and Data set 1 (DT1). All the
numbers of address, size, Data, and Default Value are indicated in 7-bit Hexadecimal-form. Numbers in the explanatory column are given in decimal notation. The MODEL ID = 45H parameters
are related to LCD display.
< MODEL ID = 45H >
Display data
Address(H) Size(H) Data(H) Parameter Description Default Value(H)
10 00 00 00 00 20 20 7F Displayed Letter 32 127(ASCII) ---
10 00 01#
10 00 02#
:
10 00 1F#
* When this message is received, a character string specified by the data will be temporarily displayed in the Instrument display area. A character string of 1 to 32 characters can be received. If
more than 16 characters are received, the display will automatically be scrolled.
Address(H) Size(H) Data(H) Parameter Description Default Value(H)
10 01 00 00 00 40 00 1F Displayed
Dot Data d00 00 31 ---
10 01 01# Dot Data d01
10 01 02# Dot Data d02
10 01 : : Dot Data :
10 01 3F# Dot Data d63
bit 4 3 2 1 0 4 3 2 1 0 4 3 2 1 0 4
[ * * d00 * * ] [ * * d16 * * ] [ * * d32 * * ] [d48]
[ * * d01 * * ] [ * * d17 * * ] [ * * d33 * * ] [d49]
[ * * d02 * * ] [ * * d18 * * ] [ * * d34 * * ] [d50]
[ * * d03 * * ] [ * * d19 * * ] [ * * d35 * * ] [d51]
[ * * d04 * * ] [ * * d20 * * ] [ * * d36 * * ] [d52]
[ * * d05 * * ] [ * * d21 * * ] [ * * d37 * * ] [d53]
[ * * d06 * * ] [ * * d22 * * ] [ * * d38 * * ] [d54]
[ * * d07 * * ] [ * * d23 * * ] [ * * d39 * * ] [d55]
[ * * d08 * * ] [ * * d24 * * ] [ * * d40 * * ] [d56]
[ * * d09 * * ] [ * * d25 * * ] [ * * d41 * * ] [d57]
[ * * d10 * * ] [ * * d26 * * ] [ * * d42 * * ] [d58]
[ * * d11 * * ] [ * * d27 * * ] [ * * d43 * * ] [d59]
[ * * d12 * * ] [ * * d28 * * ] [ * * d44 * * ] [d60]
[ * * d13 * * ] [ * * d29 * * ] [ * * d45 * * ] [d61]
[ * * d14 * * ] [ * * d30 * * ] [ * * d46 * * ] [d62]
[ * * d15 * * ] [ * * d31 * * ] [ * * d47 * * ] [d63]
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* For example, [ * * d00 * * ] indicates the five dots in the upper left of the display.
* The bit pattern of bits 4 0 (lower 5 bits) of the data byte turns the dots on/off. However, in the case of d48 d63, only bit 4 turns the dot on/off.
d00: 0--*****
d01: 0--*****
|
d47: 0--*****
d48: 0--*----
| *: dot is unlit for 0, lit for 1
d63: 0--*---- -: dot display is not affected whether this is 0 or 1
