■Dumping a list of internal sounds
●Instrument list dump
❍Instrument list dump request (receive only)
This command requests a bulk dump of a list of the preset sounds (Instruments) in internal
memory, and uses “Data Request 1 (RQ1)” format. The Size specifies the contents of the
requested data.
Address: 0C 00 01
Size: 00 00 00: ALL
00 00 01: SC-55 MAP
00 00 02: SC-88 MAP
00 00 03: SC-88Pro MAP
00 00 04: SC-8850 MAP
❍Instrument list dump (transmit only)
When Instrument List Dump Request is received, the sound names of the specified map will
be transmitted continuously in the format given below, where 16 bytes are used for each
sound name. The Address of the transmitted data is 0C 00 01 for all packets. User bank
sound names are not transmitted.
DUMP FORMAT:
fig.11-17
CC0: Variation number
MAP : MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = SC-88Pro MAP, 04 = SC-
8850 MAP
PC: Program number
●Drum set list dump
❍Drum set list dump request (receive only)
This command requests a bulk dump transmission of a list of Preset Drum Sets in internal
memory, and uses “Data Request 1 (RQ1)” format. The Size specifies the desired data
contents.
Address: 0C 00 02
Size: 00 00 00: ALL
00 00 01: SC-55 MAP
00 00 02: SC-88 MAP
00 00 03: SC-88Pro MAP
00 00 04: SC-8850 MAP
❍Drum set list dump (transmit only)
When a Drum Set List Dump Request is received, the Drum Set names of the specified MAP
will be transmitted successively in the format given below, where 16 bytes are used for each
sound. The Address of the transmitted data will be 0C 00 02 for each packet.
DUMP FORMAT:
fig.11-18
MAP: MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = SC-88Pro MAP,
04 = SC-8850 MAP
PC: Program number
●Drum instrument list dump
❍Drum instrument list dump request (receive only)
This command requests a bulk dump transmission of the Instrument list of an internal
Preset Drum Sets, and uses “Data Request 1 (RQ1)” format. The Size specifies the desired
data contents.
Address: 0C 00 03
Size: 00 00 00 ALL
00 00 01 SC-55 MAP
00 00 02 SC-88 MAP
00 00 03 SC-88Pro MAP
00 00 04 SC-8850 MAP
❍Drum instrument list dump (transmit only)
When a Drum Instrument List Dump Request is received, the Drum Instrument names of
the specified Drum Set will be transmitted in the following format where 16 bytes are used
for each Drum Instrument name. The address of the transmitted data will be 0C 00 03 for
each packet.
DUMP FORMAT:
fig.11-19
MAP: MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = SC-88Pro MAP, 04 = SC-
8850 MAP
PC: Program number
KEY: Note number
●Insertion effect list dump
❍Insertion effect list dump request (receive only)
This command requests a bulk dump transmission of the Insertion effect list of an internal
memory, and uses “Data Request 1 (RQ1)” format. The Size specifies the desired data
contents.
Address: 0C 00 04
Size: 00 00 00: ALL
❍Insertion effect list dump (transmit only)
When a Insertion Effect List Dump Request is received, the specified Insertion Effect names
will be transmitted in the following format where 20 bytes are used for each Effect name.
The address of the transmitted data will be 0C 00 04 for each packet.
DUMP FORMAT:
fig.11-20
MSB: Category
LSB: Type
0123 54 6789ABCDEF
CC0 MAP PC 00 TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
00 MAP PC 00 DRUM TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
00 MAP PC KEY DRUM TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
MSB LSB 00 00 EFFECT NAME(ASCII 16 Characters)
10 11 12 13
