42
Parts and Sounds
Bank Select LSB
The SC-8850 processes the lower part of the Bank Select message (LSB) as follows
(p.149).
Least significant byte (LSB)
0 The INST MAP settings made from the panel of the SC-8850
will be used. If [ ] is shown at the left of SC-55 in the panel
INST MAP, the SC-55 map is selected. If [ ] is shown at the
left of SC-88, the SC-88 map is selected. If [ ] is shown at
the left of SC-88Pro, the SC-88Pro map is selected. If [ ] is
shown at the left of SC-8850, the SC-8850 map is selected.
1 The SC-55 map is selected, and [ ] will appear at the left of
SC-55 in INST MAP.
2 The SC-88 map is selected, and [ ] will appear at the left of
SC-88 in INST MAP.
3 The SC-88Pro map is selected, and [ ] will appear at the left
of SC-88Pro in INST MAP.
4 The SC-8850 map is selected, and [ ] will appear at the left
of SC-8850 in INST MAP.
How to change the sound of a part using MIDI messages
<Example>
Setting the sound of Part 2 to the SC-88 map 017 Organ 1 (Variation 000)
MIDI CH = 02
CC#00 000 Selects Variation number 000
CC#32 002 Selects the SC-88 map
PC# 017 Selects Instrument number 017
How to change the variation sound of a part using MIDI messages
<Example> Setting the sound of Part 1 to the SC-8850 map 006 Detuned EP3
(Variation 009)
MIDI CH = 01
CC#00 009 Selects Variation number 009
CC#32 004 Selects the SC-8850 map
PC# 006 Selects Instrument number 006
How to change the map and variation sound of a part using MIDI messages
<Example> Setting the sound of Part 3 to the SC-88Pro map 039 Acid Bass
(Variation 008)
MIDI CH = 03
CC#00 008 Selects Variation number 008
CC#32 003 Selects the SC-88Pro map
PC# 039 Selects Instrument number 039
