Using System Effects
To change the Equalizer Low Gain using MIDI messages, transmit the following Sys-
tem Exclusive Message.
fig.8-2ae
Address: EQ LOW GAIN
Data: 34H–40H–4CH (-12–±0–+12dB)
Checksum: Refer to How to calculate the checksum (p.245).
<Example> Setting the Equalizer Low Gain to +6
Transmit the following System Exclusive Message.
fig.8-2be
F0 41 10 42 12 [ 40 02 01 ] [ ] [ ] F7
address
data
checksum
. . . .
Also refer to MIDI Imple-
mentation (p.236).
F0 41 10 42 12 [ 40 02 01 ] [ 46 ] [ 77 ] F7
address
data
checksum
EQ LOW GAIN
±0=40 ➟ +6=46
checksum
