ROMET 4E Electric Vehicle Instruction Manual
13
Voltmeter
Scale 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Value 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
Permissible
tolerance
(v)
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
±
1%
Ampere meter
Scale (from
left to right)
1 2 3 4
5 (alarming
point)
Percentage 100% 85% 70% 55% 40%
1. When the value in the voltameter is above 85%, this car can be traveling on the road;
when the voltameter is blinking and the value reaches 40%, please charge the car nearby
at once, or the battery life may be negatively affected.
2. When the ignition switch is just turned on, the car doesn’t travel and both meters show
close states.
Ampere meter
scale 8 12 14 16
Volt value (A) 100 200 300 400
Permissible
tolerance
±1 ±2 ±3 ±4
Odometer:
1. ODO represents the total mileage and it is shown with the value simultaneously. Even
keep pressing the reset button, the total mileage will not change!
2. TRIP represents subtotal mileage,
When TRIP is shown with A simultaneously, the lower line shows subtotal 1; and keep
pressing the reset button, the subtotal mileage will be reset!
When TRIP is shown with B simultaneously, the lower line shows subtotal 2; and keep
pressing the reset button, the subtotal mileage will be reset!
3. The LCD red lines, symbols and letters are always indicated.
The speed indication range: 0-80 km/h
