ROMET 4E Electric Vehicle Instruction Manual
34
2. The use of jack
(1) Place the jack under the strong point of the vehicle, and hook one end of the screw rod with the hook at front-end handle, then one hand on the jack handle, the
other cranking, ultimately the jack will raise gradually.
Place the jack on the solid and level ground as far as possible. Counterclockwise screw each nut of the vehicle one or two circles (screw diagonally). Lift the vehicle
carefully till the tire off the ground completely. Detach the nuts of the vehicle, and then remove the tire.
When only use jack to support the vehicle, do not lie under the vehicle, you should use vehicle support table. When the vehicle is supported, do not start or operate
the engine, and the passengers is not allowed to stay in the vehicle.
(2) Remove the tires
Unscrew the wheel nut by wheel nut wrench, and do not remove the wheel nut for now. Select one strong point to place the jack and then lift the vehicle till the tires
