ROMET 4E Electric Vehicle Instruction Manual
2
Power assembly
1. Type of drive: rear axle drive
2. AC motor parameter as follows:
Model No. YJM-XYQ-5-4 Power 5 kw
Voltage 72V Quota 60 min
Current 104A Speed 3000r/m
Excitation
AC asynchronous
Insulation Class F
Protection class Ip20
3. Battery pack parameters
Model No. 4-DM-150 Rated voltage 8VAC
Capacity
150AH
3HR 180AH
200AH
Total voltage 72V Quantity (R6) 9 pieces
Connection type 9 batteries in series
