Rosco Maximizer 2B User Manual

6-10 Rosco Maximizer 2B Asphalt Distributor
Operation
Operating the burners without
circulating the product can create explosive fumes.
If the product can not be circulated after 15 minutes
of heating, the fuel to the burners must be turned off,
while leaving the blowers running (15 minutes ON, 15
minutes OFF). Do not try to heat material again for
30 minutes.
9. Set asphalt pump to the forward position at a ow of
75 - 100 GPM (283.9 - 378.5 LPM).
10. Turn the fuel and blower switches on the fender
controls OFF.
NOTE: Burner Control switch is a momentary switch and
will return to the OFF position. An icon will display
on the screen when the Burner Control switch
has enabled the burner system controls.
11. Turn the Burner Control switch ON.
12. Turn lower burner blower switch on the fender
controls to ON. Wait 1 to 2 minutes to purge residual
gas fumes from system before proceeding.
13. Turn lower burner fuel switch on the fender controls
to the ON position.
NOTE: The burner should light. If it does not start
immediately, shut OFF fuel, run blower to clear
fuel from ue and retry in 1 to 2 minutes.
If the fuel is not cleared from the ue,
the fuel may backre through the burner when the
operator tries to relight it. The operator could get
burned.
NOTE: If your unit is equipped with dual diesel burners
you will have separate controls for each burner,
(Figure 6-6). This allows the operator to run one
or both of the burners to heat the material. Light
the upper burner using the same steps as with
the lower burner.
1. Be sure the unit is sitting on a level area.
Do not put your head in the tank.
Serious injury or death could result from breathing
poisonous fumes.
2. With a ash light, look into the tank from the top and
check that there is no visible water or condensation
in the tank. If there is, drain the tank to an approved
container. Dispose of material and water according
to local, state and federal regulations.
DO NOT SMOKE around the machine.
Fuel, asphalt material and the fumes from both
can explode when exposed to ame or heat from
smoking or other sources.
Hot material will turn water into steam
and can cause an explosion.
3. Be sure that ue tubes are covered by at least 8
inches of material. Read the tank dipstick. If the
amount in the tank is less than the recommended
amount in Table 6-3. Tank Contents Chart to
Ensure Flue Tube Coverage, do not use the
burners. Using the burners without enough material
in the tank will cause damage to the ue tubes and
could cause an explosion.
Never operate the burners if the ue
tubes are not covered with at least 8” of material. The
ue tubes can become red hot and ignite the vapors
causing an explosion.
4. Start and run the engine at 1000 to 1200 RPM,
engage PTO (if equipped). This provides power to
the asphalt pump.
5. Do not load, unload, transport or spray while
burners are operating.
6. Turn the Plus One Controller Master switch ON to
activate the system, (Figure 5-2,1).
7. Set the Plus One Controller to the required
temperature for the material being used, (Figure
6-10) Refer to Table 4-4..
8. Push the Mode Selection Button 2 - Tank Circulate
(Figure 6-1), (see Tank Circulate Mode in Section
6).
