Reference Manual
00809-0100-4841, Rev. AA
May 2007
C-3
Rosemount 3490 Series
RELAY 2 P420 Relay 2 Mode - None - - 4-42
P421 Relay 2 ON Point As P200 0 - - 4-42
P422 Relay 2 OFF Point As P200 0 - - 4-42
P423 Relay 2 Minimum ON Time mmm:ss 000:00 - - 4-42
P424 Relay 2 Maximum ON Time mmm:ss 000:00 - - 4-42
P425 Relay 2 Minimum OFF Time mmm:ss 000:00 - - 4-42
RELAY 3 P430 Relay 3 Mode - None - - 4-42
P431 Relay 3 ON Point As P200 0 - - 4-42
P432 Relay 3 OFF Point As P200 0 - - 4-42
P433 Relay 3 Minimum ON Time mmm:ss 000:00 - - 4-42
P434 Relay 3 Maximum ON Time mmm:ss 000:00 - - 4-42
P435 Relay 3 Minimum OFF Time mmm:ss 000:00 - - 4-42
RELAY 4 P440 Relay 4 Mode - None - - 4-42
P441 Relay 4 ON Point As P200 0 - - 4-42
P442 Relay 4 OFF Point As P200 0 - - 4-42
P443 Relay 4 Minimum ON Time mmm:ss 000:00 - - 4-42
P444 Relay 4 Maximum ON Time mmm:ss 000:00 - - 4-42
P445 Relay 4 Minimum OFF Time mmm:ss 000:00 - - 4-42
RELAY 5 P450 Relay 5 Mode - None - - 4-42
P451 Relay 5 ON Point As P200 0 - - 4-42
P452 Relay 5 OFF Point As P200 0 - - 4-42
P453 Relay 5 Minimum ON Time mmm:ss 000:00 - - 4-42
P454 Relay 5 Maximum ON Time mmm:ss 000:00 - - 4-42
P455 Relay 5 Minimum OFF Time mmm:ss 000:00 - - 4-42
ALARM P490 Rising level alarm delay mmm:ss 000:00 - - 4-57
P491 Relay operations alarm limit - 0 - - 4-56
P492 Relay operations relay select - Disabled - - 4-56
P493 Relay runtime alarm limit hh:mm 00:00 - - 4-56
P494 Relay runtime relay select - Disabled - - 4-57
P495
(4)
Pump efficiency limit - 0 - - 4-57
P496
(4)
Pump efficiency relay select - 0 - - 4-57
P497 No activity delay hh:mm 00:00 - - 4-57
P498 No activity relay hh:mm 00:00 - - 4-57
TOTALISER
(5)
Totaliser Wizard - 0 - - 4-67
P530 Totaliser [1] Factor - 0 0 - 4-63
P531 Totaliser [1] Units - 0 0 - 4-63
P532 Totaliser 2 Factor - 0 0 - 4-63
P533 Totaliser 2 Units - 0 0 - 4-63
P536 Totaliser 2 Source - 0 - - 4-63
P534 Totaliser Pulse Width ms 100 10 2500 4-63
P535 Sampler Factor - 0 0 - 4-67
MAIN MENU Menu Level 2 Menu Level 3 Menu Level 4
Param
Num.
Parameter Name Units
Factory
Defaults
Min Max
Reference
Pages
