Reference Manual
00809-0100-4841, Rev. AA
May 2007
Rosemount 3490 Series
C-4
P537
(6)
Totaliser 2 decimal places - 1 - - 4-65
ALARM P540 PV Over Limits - None - - 4-60
P541 Current Output Saturated - None - - 4-60
P542 Logging Memory Filling
(7)
- None - - 4-60
P543 Digital Input Active - None - - 4-60
P544 Maximum number of retries - None - - 4-60
P545 Current Input Saturated - None - - 4-60
P547 Rising Level - None - - 4-60
RELAY P548 Relay operations - None - - 4-60
P549 Relay runtime - None - - 4-60
P550 Pump efficiency - None - - 4-60
P551 No activity - None - - 4-60
FAULT P560 System Fault - Both - - 4-52
P561 CU Temp Fault - None - - 4-52
P562 Transmitter Fault - Both - - 4-52
DISPLAY P570 Display Select 1 (upper) - P731-Time - - 4-72
P571 Display Select 2 (mid) - D800-PV - - 4-72
P572 Display Select 3 (lower) - Bargraph - - 4-72
P573 Decimal places - 3 - - 4-72
P574 Display size - Large - - 4-72
P575 Back light On/Off - On - - 4-72
LOGGING
(7)
Logging Wizard - 0 - - 4-37
P590 Logging Interval min 0 0 99 4-35
P591 Fast logging select mode as P200 0 (=Off) 0 - 4-35
P592 Do/Do not overwrite old data - On - - 4-35
P593 Low memory alarm threshold % 0 0 99 4-35
INPUT CHANNEL
(Models 3491/3493)
P111 Channel 1 Input Source Tx1 : PV - - 4-14, 4-20
P321 Current Input 1 Damping sec 5 0 99.9 4-14, 4-20
P112 Channel 1 Input Offset - 0 - - 4-14, 4-20
P113 Channel 1 Profile - Scaled - - 4-14, 4-20
P114 Channel 1 Input Scale Factor - 1 - - 4-13, 4-24
P115 Channel 1 Non-Linear Data - 0 - - 4-13, 4-24
P116 Channel 1 Post Scale - 1 - - 4-13, 4-24
P117 Channel 1 Low Cut-off as P201 AUTO - - 4-14, 4-20
PV
CALCULATION
(Model 3492)
CHANNEL 1 P111 Channel 1 Input Source Tx1 : PV - - 4-14, 4-20
P112 Channel 1 Input Offset - 0 - - 4-14, 4-20
P113 Channel 1 Profile - Scaled - - 4-14, 4-20
P114 Channel 1 Input Scale Factor - 1 - - 4-13, 4-24
P115 Channel 1 Non-Linear Data - 0 - - 4-13, 4-24
P116 Channel 1 Post Scale - 1 - - 4-13, 4-24
P117 Channel 1 Low Cut-off as P201 AUTO - - 4-14, 4-20
MAIN MENU Menu Level 2 Menu Level 3 Menu Level 4
Param
Num.
Parameter Name Units
Factory
Defaults
Min Max
Reference
Pages
