Rosemount 3490 Series
PV
CALCULATION
(Model 3492)
CHANNEL 2 P121 Channel 2 Input Source Tx2 : PV - - 4-17, 4-22
P122 Channel 2 Input Offset - 0 - - 4-14, 4-20
P123 Channel 2 Profile - Scaled - - 4-14, 4-20
P124 Channel 2 Input Scale Factor - 1 - - 4-13, 4-24
P125 Channel 2 Non-Linear Data - 0 - - 4-13, 4-24
P126 Channel 2 Post Scale - 1 - - 4-13, 4-24
P127 Channel 2 Low Cut-off as P202 AUTO - - 4-14, 4-20
P150 Output Mapping - Ch1 - - 4-22
P151 MCU Fourth Variable Source - Tx1: FV - - 4-22
P321 Current Input 1 Damping sec 5 0 99.9 4-14, 4-20
DIGITAL INPUT DIGITAL INPUT 1 P340 Digital Input 1 Action - Free - - 4-34
P341 Digital Input 1 Delay mmm.ss 000:00 - - 4-34
P342 Digital Input 1 Active - Closed - - 4-34
DIGITAL INPUT 2 P345 Digital Input 2 Action - Free - - 4-34
P346 Digital Input 2 Delay mmm:ss 000:00 - - 4-34
P347 Digital Input 2 Active - Closed - - 4-34
SYSTEM TEST SIMULATION Simulation - - - - 5-2
DISPLAY Display Test - - - - 5-2
CURRENT I/P 4mA input adjust - - - - 5-3
20mA input adjust - - - - 5-3
CURRENT O/P P700 4mA output adjust - - - - 5-3
P701 20mA output adjust - - - - 5-3
P702 Set Current mA 0 - - 5-3
DEFAULTS LOAD DEFAULTS - - - - D-1
COMMS P710 Comms address of control unit - 0 0 15 4-74
P711 Interface type - See
(8)
-- 4-74
P712 Baud rate - See
(9)
-- 4-74
P713 Number of start bits - 1 1 2 4-74
P714 Number of data bits - 8 7 8 4-74
P715 Parity of data - Odd - - 4-74
P716 Number of stop bits - 1 1 2 4-74
SETTINGS P730 Date - (Factory set) - - 4-12
P731 Time - - - - 4-12
P734 Date format - dd/mm/yy - - 4-12
P735 Keypad sound on/off - On - - 4-12
P737 Language - English - - 4-12
P740 Personal ID code (PIN) - 0 - - 4-75
Xmtr Wizard - - - -
FIXED D750 Model code - (Factory set) - - 5-7
D751 Serial Number - Control Unit - (Factory set) - - 5-7
D752 Hardware Revision - (Factory set) - - 5-7
MAIN MENU Menu Level 2 Menu Level 3 Menu Level 4
Param
Num.
Parameter Name Units
Factory
Defaults
Min Max
Reference
Pages
